Pro Clima Fronta Quattro
Pro Clima Solitex Fronta Quattro is a windtight external breather membrane for walls where open jointed cladding will be installed. The plain black non-printed surface provides a pleasing appearance when visible through open cladding.
Next Day Pallet
Economy Pallet
Parcel Delivery
Pro Clima Solitex Fronta Quattro is a windtight external breather membrane for walls where open jointed cladding will be installed. The plain black non-printed surface provides a pleasing appearance when visible through open cladding. The Solitex membrane is extremely stable when exposed to UV and radiant heat from the sun. It can be left exposed during construction for up to 6 months on walls before cladding is installed or as a temporary roof covering before using it on the walls.
Installation
- Roll out the membrane horizontally and fix to the structure with at least 10mm wide and 8mm long galvanised staples. Overlap each length of membrane so any water run-off cannot get behind the membrane. Line up the edges of overlapping membrane with the dotted line to obtain the correct amount of overlap.
- Use Tescon Invis airtight tape to seal the overlap. Be careful so as to avoid any wrinkles. For sealing onto rough surfaces or concrete use Orcon F Airtight Adhesive.
- To seal to a window or door frame use Tescon Profil Airtight Window Tape or Tescon Invis.
Hints and Tips
- Solitex Fronta Quattro must always be installed with its plain black surface facing outwards (towards the environment). This is the weatherproof side.
- When installed on walls horizontally, lengths of membrane higher up the wall should overlap on top of membrane lower down and then be taped.
- This can be achieved by applying the first length of membrane at the bottom of the wall and then working upwards.
- This prevents water run-off getting behind the membrane and is an additional level of protection against rainwater penetration.
Suitable For
- External walls where open jointed cladding, with gaps of up to 35mm in width, will be used.
Coverage Rate
- 75m²
- Plain black and unprinted
- Easy to install
- UV resistant
- Totally windtight
- Fully black discreet membrane looks best behind open jointed cladding; no branding can be seen through cladding gaps.
- Printed guides on the edges make it easy to correctly seal overlaps and are hidden by tape once installation is complete.
- Excellent UV resistance ensures long term safety against UV exposure behind cladding and can be used as temporary covering during construction.
- The 3-layer polypropylene monolithic membrane with an integrated TEEE layer offers a fully vapour open yet totally windtight structure
- 1.5m x 50m roll
